Punch P2 6.5” 2-Way High-Output Convertible Speakers P2V2-65HO

Punch P2 6.5” 2-Way High-Output Convertible Speakers P2V2-65HO

$599.95Price

The family of P2 PUNCH speakers were engineered to fit and built to put you in control. With a versatile convertible design, these speakers can be configured as either component or coaxial systems to suit your setup. The internal/external crossovers and redesigned frame geometry ensures seamless integration and installation. A larger motor, precision-tuned tweeter configuration, and ultra-durable materials deliver relentless output and uncompromising reliability.

Auto Fit Architecture: Everything was engineered to fit. A re-designed frame, mounting holes, removable motor cover and speaker diameter were all engineered to ensure seamless integration into today’s modern vehicles. Our factory location mounting flanges provide a flexible yet precise alignment for drop-in integration into most factory mounting locations.

Superior Flexibility: With a versatile convertible design, these speakers can be configured as either component or coaxial systems to suit your setup. The Interchangeable Locking Mechanism (I.L.M.) lets you lock and unlock the tweeter from the wired mounting cup with zero hassle. This flexible design allows you to take even more control over your install layout and tweeter location. All engineered to ensure a seamless fit in most modern vehicles and to make installation as smooth and adaptable as possible.

Performance Driven: Powered by our advanced VAST 2.0™ technology, the PUNCH series delivers a 25% increase in cone area, resulting in maximum output and deeper, more impactful bass. The inverted dome tweeter ensures a precise high-frequency range, so every note comes through with clarity and accuracy. Rated at 75W RMS and 150W peak, PUNCH speakers deliver the output you demand, loud, clean, and relentless.

Built to Last: Every component. Every material. Chosen for strength. Built for the long haul. From reinforced polymer baskets to Santoprene™ surrounds and Nomex® spiders, every part of the PUNCH speaker is engineered to be a workhorse. No matter how hard you drive them, the class-leading construction delivers relentless performance that lasts.

Quantity

    CTA-2031 Compliant

    Speaker Type

    Convertible

    Midrange Size
    (Nominal Diameter)

    6.5"

    Tweeter Size
    (Nominal Diameter)

    3/4" (19mm)

    Piezo Size
    (Nominal Diameter)

    Nominal Impedance
    (Ohms)

    Frequency Response
    (Hz)

    49Hz - 25kHz

    Voice Coil Diameter
    (in/mm)

    1.25" (32.5 mm)

    Crossover

    Tweeter High-Pass: 9kHz @ 6dB/octave (internal)
    Tweeter High-Pass: 9kHz @ 12dB/octave (external)
    Tweeter Attenuation: 0dB or -3dB (external)

    Power Handling
    (Watts RMS)

    75 Watts RMS
    150 Watts Peak

    Fs (Hz)

    65 Hz

    Sensitivity
    (dB @ 1W/1M)

    88 dB

    Sensitivity
    (2.83V/1M)

    91 dB

    Cutout Diameter

    5.42" (137.6 mm)

    Rear-Loading Depth
    (Twist-Lock Adaptor)

    Front-Loading Depth
    (Twist-Lock Adaptor)

    Mounting Depth
    (With Motor Cover)

    2.5" (63.5 mm)

    Min. Mounting Depth
    (No Motor Cover)

    2.26" (57.3 mm)

    Front Side Clearance

    0.43" (11 mm)

    Removable Motor Cover

    Yes

    Grille/Trim Ring Included

    No

    Included in the Box

    (2) 3/4" 2Ω Tweeters
    (2) 6.5" 2Ω Speakers
    (1) 6.5" Speaker Cut-Out Template
    (4) Self-Tapping Phillips #4x16mm (Tweeter)
    (8) Self-Tapping Phillips #8x32mm (Speaker)
    (4) Self-Tapping Phillips #8x20mm (Crossover)
    (2) Woofer Phase Plugs
    (2) Flush-Mount Tweeter Cups
    (2) Surface-Mounting Tweeter Cups
    (1) Tweeter Removal Tool
    (2) HO Passive Crossover Network (Tweeter)
    (2) 18” Crossover Wiring Extensions
    (2) 18 AWG Red/Black Speaker Wire, 205 mm
    (3) 18 AWG (–) Female Crimp Spade Conn. (.187”)
    (3) 18 AWG (+) Female Crimp Spade Conn. (.250”)
    (4) 18 AWG Crimp Butt Connectors
    (6) Zip Ties 4.8 mm x 350 mm

    Mounting Hardware

    Yes

    Shipping Weight

    7 Lbs. (3.18 Kg.)
